Infineon Applied sciences AG at this time introduced the addition of the EZ-USB FX20 programmable USB peripheral controller to its EZ-USB product household. It allows builders to create USB units that meet the best efficiency necessities in AI, picture processing and rising functions. The EZ-USB FX20 peripheral controller affords high-speed connectivity with USB 20 Gbps and LVDS interfaces, growing the overall bandwidth as much as six occasions over its predecessor, the EZ-USB FX3.
“With the rising recognition of USB units, the demand for suitable and adaptable USB controllers is growing,” mentioned Ganesh Subramaniam, Senior Vice President and Normal Supervisor of the Wired Connectivity Options Product Line at Infineon. “Subsequently, we’re constantly enhancing the options and efficiency of our EZ-USB peripheral controllers and are happy to help builders with our new addition to the product household, offering them with a versatile element to create highly effective and superior functions.”
The EZ-USB FX20 is available in a ten x 10 mm² BGA package deal and requires little PCB area. This permits BOM optimization and is right for space-constrained functions. It additionally helps direct USB-C connection with out a high-speed sign multiplexer, simplifying the design course of. The fast-start growth package contains firmware and a configuration instrument for simple integration. It comes with a typical FPGA Mezzanine Card (FMC) connector for simple connection to Subject Programmable Gate Array (FPGA) playing cards and an all-in-one programming and debugging accent card. As well as, the peripheral controller affords a complete set of software notes for {hardware} and software program design to simplify the event of high-performance units for varied functions.
The EZ-USB FX20 is provided with two ARM Cortex-M4 and M0+ core CPUs, 512 KB Flash, 128 KB SRAM, 128 KB ROM and 7 serial communication blocks (SCBs). It additionally features a cryptography accelerator and a high-bandwidth information subsystem that permits Direct Reminiscence Entry (DMA) information transfers between LVDS/LVCMOS and USB ports at speeds of as much as 20 Gbps. Knowledge switch can also be supported by an extra 1 MB of SRAM for USB information buffering. Because the peripheral controller integrates USB-C port orientation detection and flip-mux performance, no exterior logic is required. All these options make the EZ-USB FX20 a perfect alternative for builders requiring a strong and adaptable USB controller.
